ICE2A265

DIP8, SMPS Current Mode Controller, 2.0 A

Rated 5 Rating 5 | reviews | Write a review

Price:: US $0.66~0.88 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
	US $0.66~0.88

PartNumber:: ICE2A265

Brand:: Infineon Technologies AG - Infineon | Pack: DIP | D/C: 08+

Availability:: Supply Ability: 10000/Week Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Sold By

Mr. Zou pinhui's store

(China (Mainland))

add to my favourite

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2011-07-09

From Other Seller

Part Number:ICE2A265
US $0.66 - 0.88
iphone5 data cable

US $4.00 - 5.00 / Piece
(0) Remove
HCPL-7800A

US $2.50 - 4.10 / Piece
(0) Remove
Quantity:

piece

Product Summary

The second generation ICE2A265 provides several special enhancements to satisfy the needs for low power standby and protection features. In standby mode frequency reduction is used to lower the power consumption and support a stable output voltage in this mode. The frequency reduction is limited to 21.5 kHz to avoid audible noise. In case of failure modes like open loop, overvoltage or overload due to short circuit the device switches in Auto Restart Mode which is controlled by the internal protection unit. By means of the internal precise peak current limitation the dimension of the transformer and the secondary diode of the ICE2A265 can be lower which leads to more cost efficiency.

Parametrics

ICE2A265 absolute maximum ratings: (1)Drain Source Voltage, VDS: 650 V max. Tj = 110℃; (2)Drain Source Voltage, VDS: 800 V Tj = 25℃; (3)Pulsed drain current, tp limited by Tjmax: ID_Puls1 2.0 A max; (4)Avalanche energy, repetitive tAR limited by max. Tj=150℃1, EAR3 0.40 mJ max,IAR3: 2 A max.; (5)VCC Supply Voltage, VCC: -0.3~22 V; (6)FB Voltage, VFB: -0.3~6.5 V; (7)SoftS Voltage, VSoftS: -0.3 V min, 6.5 V max; (8)ISense ISense: -0.3 V min, 3 V max.

Features

ICE2A265 features: (1)650V/800V Avalanche Rugged CoolMOS Only few external Components required; (2)Input Undervoltage Lockout; (3)100kHz Switching Frequency; (4)Max Duty Cycle 72%; (5)Low Power Standby Mode to meet European; (6)Commission Requirements; (7)Thermal Shut Down with Auto Restart; (8)Overload and Open Loop Protection; (9)Overvoltage Protection during Auto Restart; (10)Adjustable Peak Current Limitation via External Resistor; (11)Overall Tolerance of Current Limiting < %; (12)Internal Leading Edge Blanking; (13)User defined Soft Start; (14)Soft Switching for Low EMI.
